Dataset Title:  Dissolved macronutrient concentrations from incubation experiments performed
on RVIB Nathaniel B. Palmer cruise NBP 16-08 from September to October 2016
Subscribe RSS
Institution:  BCO-DMO   (Dataset ID: bcodmo_dataset_743072)
Information:  Summary ? | License ? | ISO 19115 | Metadata | Background (external link) | Subset | Data Access Form | Files

Graph Type:  ?
X Axis:
Y Axis:
Color:
-1+1

Constraints ? Optional
Constraint #1 ?
Optional
Constraint #2 ?






Server-side Functions ?
 distinct() ?
? ("Hover here to see a list of options. Click on an option to select it.Hover here to see a list of options. Click on an option to select it.Hover here to see a list of options. Click on an option to select it.Hover here to see a list of options. Click on an option to select it.")

Graph Settings
Marker Type:   Size:
Color:
Color Bar:   Continuity:   Scale:
   Minimum:   Maximum:   N Sections:
Y Axis Minimum:   Maximum:

(Please be patient. It may take a while to get the data.)

Optional:
Then set the File Type: (File Type information)
and
or view the URL:
(Documentation / Bypass this form ? )
    [The graph you specified. Please be patient.]



Things You Can Do With Your Graphs

Well, you can do anything you want with your graphs, of course. But some things you might not have considered are:

The Dataset Attribute Structure (.das) for this Dataset

Attributes {
 s {
  INCUBATION {
    Byte _FillValue 127;
    Byte actual_range 1, 3;
    String bcodmo_name "exp_id";
    String description "Incubation identifier";
    String long_name "INCUBATION";
    String units "unitless";
  }
  DATE {
    String bcodmo_name "date";
    String description "GMT date when incubation sample was pulled from the incubation bottle for filtering, in format yyyy-mm-dd";
    String long_name "DATE";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/ADATAA01/";
    String source_name "DATE";
    String time_precision "1970-01-01";
    String units "unitless";
  }
  DAY {
    Byte _FillValue 127;
    Byte actual_range 0, 14;
    String bcodmo_name "incubation time";
    String description "Day of incubation when sample was collected. Days start from 0 for the day the incubation was setup.";
    String long_name "DAY";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/AZDRZZ01/";
    String units "unitless";
  }
  ID {
    String bcodmo_name "sample";
    String description "Sample identifier for incubation bottle and treatment that sample was collected from.";
    String long_name "ID";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P02/current/ACYC/";
    String units "unitless";
  }
  TREATMENT {
    String bcodmo_name "treatment";
    String description "Incubation treatment identifier. Treatments A-F were exposed to light, treatments G-L were kept in the dark. Treatments were as follows: A and G = +0, control; B and H = +1 nM 57FeCl3; C and I = +4 nM Fe 57FeCl3; D and J = +10 nM Fe 57FeCl3; E and K = +600 pM Vitamin B12; F and L = +4 nM 57FeCl3 and +600 pM Vitamin B12. The R-A, R-B, R-C, R-D, R-E, and R-F bottles were the same light treatments as A, B, C, D, E, and F, respectively, in replicate R-labeled 4-L incubation bottles.";
    String long_name "TREATMENT";
    String units "unitless";
  }
  BTLNBR {
    String bcodmo_name "bottle";
    String description "Incubation bottle number. Each 4-L incubation bottle was assigned a unique number from 1-99 across all shipboard incubations.";
    String long_name "BTLNBR";
    String units "unitless";
  }
  NO3_NO2 {
    String bcodmo_name "NO3_NO2";
    String description "Concentration of dissolved nitrate+nitrite. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value. Noted as \"bdl\" when result was below detection limit of instrument(s) used.";
    String long_name "NO3 NO2";
    String units "micromoles per liter (uM)";
  }
  NO3_NO2_STDEV {
    String bcodmo_name "NO3_NO2";
    String description "Standard deviation of replicate nitrate+nitrite concentration measurements. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NO3 NO2 STDEV";
    String units "micromoles per liter (uM)";
  }
  NO3_NO2_pcnt_RSD {
    String bcodmo_name "NO3_NO2";
    String description "Percent relative standard deviation of replicate nitrate+nitrite concentration measurements. Calculated as NO3_NO2_STDEV divided by NO3_NO2 and multiplied by 100. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NO3 NO2 Pcnt RSD";
    String units "unitless (percent)";
  }
  NO3_NO2_INSTR {
    Byte _FillValue 127;
    Byte actual_range 1, 3;
    String bcodmo_name "instrument";
    Float64 colorBarMaximum 50.0;
    Float64 colorBarMinimum 0.0;
    String description "Notes which instrument was used for nitrate+nitrite measurements. 1 = Lachat 8500 QuickChem, 2 = Technicon AAII, 3 = Both Lachat 8500 QuickChem and Technicon AAII. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "Mole Concentration Of Nitrate In Sea Water";
    String units "unitless";
  }
  PO4 {
    Float32 _FillValue NaN;
    Float32 actual_range 0.1, 2.37;
    String bcodmo_name "PO4";
    String description "Concentration of dissolved reactive phosphate. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value. Noted as \"bdl\" when result was below detection limit of instrument(s) used.";
    String long_name "Mass Concentration Of Phosphate In Sea Water";
    String units "micromoles per liter (uM)";
  }
  PO4_STDEV {
    String bcodmo_name "PO4";
    String description "Standard deviation of replicate phosphate concentration measurements. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "PO4 STDEV";
    String units "micromoles per liter (uM)";
  }
  PO4_pcnt_RSD {
    String bcodmo_name "PO4";
    String description "Percent relative standard deviation of replicate phosphate concentration measurements. Calculated as PO4_STDEV divided by PO4 and multiplied by 100. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "PO4 Pcnt RSD";
    String units "unitless (percent)";
  }
  PO4_INSTR {
    Byte _FillValue 127;
    Byte actual_range 1, 3;
    String bcodmo_name "instrument";
    String description "Notes which instrument was used for phosphate measurements. 1 = Lachat 8500 QuickChem, 2 = Technicon AAII, 3 = Both Lachat 8500 QuickChem and Technicon AAII. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "Mass Concentration Of Phosphate In Sea Water";
    String units "unitless";
  }
  SiO4 {
    Float32 _FillValue NaN;
    Float32 actual_range 24.01, 88.91;
    String bcodmo_name "SiO4";
    String description "Concentration of dissolved silicate. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value. Noted as \"bdl\" when result was below detection limit of instrument(s) used.";
    String long_name "Si O4";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/SLCAAAZX/";
    String units "micromoles per liter (uM)";
  }
  SiO4_STDEV {
    String bcodmo_name "SiO4";
    String description "Standard deviation of replicate silicate concentration measurements. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "Si O4 STDEV";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/SLCAAAZX/";
    String units "micromoles per liter (uM)";
  }
  SiO4_pcnt_RSD {
    String bcodmo_name "SiO4";
    String description "Percent relative standard deviation of replicate silicate concentration measurements. Calculated as SiO4_STDEV divided by SiO4 and multiplied by 100. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "Si O4 Pcnt RSD";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/SLCAAAZX/";
    String units "unitless (percent)";
  }
  SiO4_INSTR {
    Byte _FillValue 127;
    Byte actual_range 1, 3;
    String bcodmo_name "instrument";
    String description "Notes which instrument was used for silicate measurements. 1 = Lachat 8500 QuickChem, 2 = Technicon AAII, 3 = Both Lachat 8500 QuickChem and Technicon AAII. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "Si O4 INSTR";
    String units "unitless";
  }
  NO2 {
    String bcodmo_name "NO2";
    String description "Concentration of dissolved nitrite. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value. Noted as \"bdl\" when result was below detection limit of instrument(s) used.";
    String long_name "NO2";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/NTRIAAZX/";
    String units "micromoles per liter (uM)";
  }
  NO2_STDEV {
    String bcodmo_name "NO2";
    String description "Standard deviation of replicate nitrite concentration measurements. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NO2 STDEV";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/NTRIAAZX/";
    String units "micromoles per liter (uM)";
  }
  NO2_pcnt_RSD {
    String bcodmo_name "NO2";
    String description "Percent relative standard deviation of replicate nitrite concentration measurements. Calculated as NO2_STDEV divided by NO2 and multiplied by 100. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NO2 Pcnt RSD";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/NTRIAAZX/";
    String units "unitless (percent)";
  }
  NO2_INSTR {
    String bcodmo_name "instrument";
    String description "Notes which instrument was used for nitrite measurements. 1 = Lachat 8500 QuickChem, 2 = Technicon AAII, 3 = Both Lachat 8500 QuickChem and Technicon AAII. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NO2 INSTR";
    String units "unitless";
  }
  NH4 {
    String bcodmo_name "Ammonium";
    String description "Concentration of dissolved ammonium. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value. Noted as \"bdl\" when result was below detection limit of instrument(s) used.";
    String long_name "NH4";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/AMONAAZX/";
    String units "micromoles per liter (uM)";
  }
  NH4_STDEV {
    String bcodmo_name "Ammonium";
    String description "Standard deviation of replicate ammonium concentration measurements. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NH4 STDEV";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/AMONAAZX/";
    String units "micromoles per liter (uM)";
  }
  NH4_pcnt_RSD {
    String bcodmo_name "Ammonium";
    String description "Percent relative standard deviation of replicate ammonium concentration measurements. Calculated as NH4_STDEV divided by NH4 and multiplied by 100. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NH4 PCNT RSD";
    String nerc_identifier "https://vocab.nerc.ac.uk/collection/P01/current/AMONAAZX/";
    String units "unitless (percent)";
  }
  NH4_INSTR {
    String bcodmo_name "instrument";
    String description "Notes which instrument was used for ammonium measurements. 1 = Lachat 8500 QuickChem, 2 = Technicon AAII, 3 = Both Lachat 8500 QuickChem and Technicon AAII. Noted as \"nda\" when no data available for this sample, no sample analyzed, or obviously erroneous data value.";
    String long_name "NH4 INSTR";
    String units "unitless";
  }
 }
  NC_GLOBAL {
    String access_formats ".htmlTable,.csv,.json,.mat,.nc,.tsv";
    String acquisition_description
"Sampling and analytical procedures:
 Incubation 1 was setup from unfiltered seawater collected aboard the R/V/I/B
Nathanial B. Palmer using a SeaBird GEOTRACES style SBE32 rosette system
deployed on a conducting Kevlar line with OceanTestEquipment, Inc. X-Niskin
samplers modified for trace element sampling. Seawater was collected from
three consecutive casts to 25-35 m depth at -62.332N, -64.647E and the
seawater from each cast was homogenized in three acid-cleaned and Milli-Q
(>18.2 M\\u03a9 cm) conditioned 50-L polypropylene carboys, then distributed
into acid-cleaned and Milli-Q conditioned 4-L polycarbonate incubation bottles
that were rinsed three times with the seawater prior to filling. Once filled,
incubation bottles were spiked with their treatments in laminar flow hoods in
a shipboard trace metal bubble, sealed with the caps wrapped in parafilm and
placed in a 2 \\u00baC temperature-controlled lit incubator van with 24 hour
blue light (Hopkinson et al. 2007). Dark treatment bottles were placed in the
same van but wrapped in heavy-duty black construction garbage bags.

Incubation 2\\u00a0was setup from unfiltered seawater collected aboard the
R/V/I/B Nathanial B. Palmer using a SeaBird GEOTRACES style SBE32 rosette
system deployed on a conducting Kevlar line with OceanTestEquipment, Inc.
X-Niskin samplers modified for trace element sampling. Seawater was collected
from two consecutive casts to 25-35 m depth at -62.46N, -59.565E and the
seawater from each cast was homogenized in three acid-cleaned and Milli-Q
(>18.2 M\\u03a9 cm) conditioned 50-L polypropylene carboys, then distributed
into acid-cleaned and Milli-Q conditioned 4-L polycarbonate incubation bottles
that were rinsed three times with the seawater prior to filling. Once filled,
incubation bottles were spiked with their treatments in laminar flow hoods in
a shipboard trace metal bubble, sealed with the caps wrapped in parafilm and
placed in a 2 \\u00baC temperature-controlled lit incubator van with 24 hour
blue light (Hopkinson et al. 2007). Dark treatment bottles were placed in the
same van but wrapped in heavy-duty black construction garbage bags.

Incubation 3\\u00a0was setup from a combination of filtered and unfiltered
seawater collected aboard the R/V/I/B Nathanial B. Palmer using a SeaBird
GEOTRACES style SBE32 rosette system deployed on a conducting Kevlar line with
OceanTestEquipment, Inc. X-Niskin samplers modified for trace element
sampling. Seawater was collected from one cast to 25-35 m depth at -62.46N,
-59.565E, the location of Incubation 2, filtered through a 0.2 um Acropak
membrane capsule filter (Pall) and stored in an acid-cleaned and Milli-Q
(>18.2 M\\u03a9 cm) conditioned 50-L polypropylene carboy. Additional
unfiltered seawater was collected from one cast to 25-35 m depth at -62.332N,
-64.647E, the location of Incubation 1, and homogenized in two acid-cleaned
and Milli-Q (>18.2 M\\u03a9 cm) conditioned 50-L polypropylene carboys. The
unfiltered water from the Incubation 1 station was distributed into acid-
cleaned and Milli-Q conditioned 4-L polycarbonate incubation bottles that were
rinsed three times with the seawater prior to filling and used for one
treatment of Incubation 3 (Q in the light, V in the dark). The filtered
seawater from the Incubation 2 station was mixed in a 50:50 ratio with the
unfiltered water from the Incubation 1 station in acid-cleaned and Milli-Q
conditioned 4-L polycarbonate incubation bottles that were rinsed three times
with the seawater prior to filling and used for the second treatment in
Incubation 3 (R in the light, W in the dark). Once filled, incubation bottles
were sealed with the caps wrapped in parafilm and placed in a 2 \\u00baC
temperature-controlled lit incubator van with 24 hour blue light (Hopkinson et
al. 2007). Dark treatment bottles were placed in the same van but wrapped in
heavy-duty black construction garbage bags.

For all incubations, samples for macronutrients were filtered through
sequential 5 um and 0.4 um acid-cleaned polycarbonate track etched filters
(Whatman Nuclepore) on Teflon filtration rigs (Savillex) and the filtrate
collected in 50 mL Falcon tubes that had been rinsed with distilled water
(DIW), soaked overnight in 10% hydrocholoric acid (HCl, Fisher, Trace Metal
Grade), rinsed three times with DIW again, dried and rinsed three times with
sample prior to filling. Samples were analyzed shipboard, typically within 24
hours, for nitrate+nitrite, phosphate, silicate, and occasionally nitrite.
Until analyzed shipboard, samples were stored sealed at 4 \\u00baC in the dark
and, following analyses, samples were frozen at -20 \\u00baC and shipped back
to the University of South Florida for laboratory-based analyses of nitrite
and ammonium, and in some cases again for nitrate+nitrite, phosphate and
silicate.

Analytical methodology was based on established methods (Parsons 1984; Gordon
et al. 1993) as described for the Lachat 8500 QuickChem in the Lachat
QuickChem methods manuals and for the Technicon AAII in the CARIACO methods
manual. All labware were either glass or high density polyethylene and were
cleaned by an initial distilled water (DIW) rinse, followed by an overnight
10% hydrochloric acid (Fisher, Trace Metal Grade) soak, then rinsed three
times with DIW and three times with solvent, analyte or sample prior to fill.
Dedicated glassware was used for reagents and standards to avoid cross
contamination issues. All reagents were made in high purity Milli-Q (>18
M\\u03a9 cm) water.

An artificial seawater matrix was used as the carrier for the analyses on the
Lachat QuickChem 8500 at sea and on the Technicon AAII in the lab. 4L batches
of artificial seawater were made by dissolving pre-weighed salts (128.50 g
NaCl, 28.50 g MgSO4*7H2O, 0.6714 g NaHCO3) in Milli-Q to match Southern Ocean
seawater salinity and adjusted to match Southern Ocean seawater pH with 10%
hydrochloric acid.

Five-point standard curves were analyzed in duplicate at the beginning and end
of each run with duplicate reagent blanks, and quality control checks every
seventh sample. Quality control check consisted of either an international
reference sample or a quality control sample. The certified nutrient reference
samples used, lots CC and CD, were purchased from Kanso Technos in Osaka,
Japan. The quality control sample was made from a 20-L homogenized surface
Southern Ocean filtered and autoclaved seawater sample. The midpoint standard
from the calibration curve was also analyzed every fourteenth sample to check
for drift during the runs.

Detection limits for all five parameters on the two instruments used were
determined from three times the standard deviation of replicate artificial
seawater blanks (n>6). On the Lachat QuickChem 8500, limits of detection were
0.01 uM for nitrate+nitrite, 0.02 uM for phosphate, 0.03 uM for silicate, 0.05
uM for nitrite and 0.5 uM for ammonium. On the Technicon AAII, limits of
detection were 0.06 uM for nitrate+nitrite, 0.02 uM for phosphate, 0.2 uM for
silicate, 0.01 uM for nitrite, and 0.05 uM for ammonium.

Sample analyses for macronutrients were performed by William Abbott (USF).

Gordon, L.I., Jennings, J., J.C., Ross, A.A. and Krest, J.M. 1993. A suggested
protocol for continuous flow automated analysis of seawater nutrients
(phosphate, nitrate, nitrite and silicic acid) in the WOCE Hydrographic
Program and the Joint Global Ocean Fluxes Study, Methods Manual WHPO 91-1.
WOCE Hydrographic Program Office.

Hopkinson, B. M., B. G. Mitchell, R. A. Reynolds, H. Wang, K. E. Selph, C. I.
Measures, C. D. Hewes, O. Holm-Hansen, and K. A. Barbeau. 2007. Iron
limitation across chlorophyll gradients in the southern Drake Passage:
Phytoplankton responses to iron addition and photosynthetic indicators of iron
stress. Limnology and Oceanography 52: 2540-2554.

Parsons, T.R., Maita, Y. and Lalli, C.M. 1984. A manual of chemical and
biological methods for seawater analysis. Pergammon Press, Oxford, 173 pp.";
    String awards_0_award_nid "738581";
    String awards_0_award_number "OPP-1443483";
    String awards_0_data_url "http://www.nsf.gov/awardsearch/showAward.do?AwardNumber=1443483";
    String awards_0_funder_name "NSF Office of Polar Programs (formerly NSF PLR)";
    String awards_0_funding_acronym "NSF OPP";
    String awards_0_funding_source_nid "713360";
    String awards_0_program_manager "Jennifer Burns";
    String awards_0_program_manager_nid "50508";
    String awards_1_award_nid "738586";
    String awards_1_award_number "OPP-1443474";
    String awards_1_data_url "https://www.nsf.gov/awardsearch/showAward?AWD_ID=1443474";
    String awards_1_funder_name "NSF Office of Polar Programs (formerly NSF PLR)";
    String awards_1_funding_acronym "NSF OPP";
    String awards_1_funding_source_nid "713360";
    String awards_1_program_manager "Jennifer Burns";
    String awards_1_program_manager_nid "50508";
    String awards_2_award_nid "738588";
    String awards_2_award_number "OPP-1443646";
    String awards_2_data_url "https://www.nsf.gov/awardsearch/showAward?AWD_ID=1443646";
    String awards_2_funder_name "NSF Office of Polar Programs (formerly NSF PLR)";
    String awards_2_funding_acronym "NSF OPP";
    String awards_2_funding_source_nid "713360";
    String awards_2_program_manager "Jennifer Burns";
    String awards_2_program_manager_nid "50508";
    String cdm_data_type "Other";
    String comment
"NBP16-08 Incubation Nutrients
  PI: Kristen Buck (USF)
  Co-PIs: Bethany Jenkins (URI) & P. Dreux Chappell (Old Dominion)
  Version date: 31 July 2018";
    String Conventions "COARDS, CF-1.6, ACDD-1.3";
    String creator_email "info@bco-dmo.org";
    String creator_name "BCO-DMO";
    String creator_type "institution";
    String creator_url "https://www.bco-dmo.org/";
    String data_source "extract_data_as_tsv version 2.3  19 Dec 2019";
    String date_created "2018-07-31T19:17:30Z";
    String date_modified "2020-01-03T17:11:10Z";
    String defaultDataQuery "&time<now";
    String doi "10.1575/1912/bco-dmo.743072.1";
    String history
"2022-08-20T04:59:09Z (local files)
2022-08-20T04:59:09Z https://erddap.bco-dmo.org/tabledap/bcodmo_dataset_743072.das";
    String infoUrl "https://www.bco-dmo.org/dataset/743072";
    String institution "BCO-DMO";
    String instruments_0_acronym "FIA";
    String instruments_0_dataset_instrument_description "Lachat QuickChem 8500 series 2, 4 channel analyzer";
    String instruments_0_dataset_instrument_nid "743112";
    String instruments_0_description "An instrument that performs flow injection analysis. Flow injection analysis (FIA) is an approach to chemical analysis that is accomplished by injecting a plug of sample into a flowing carrier stream. FIA is an automated method in which a sample is injected into a continuous flow of a carrier solution that mixes with other continuously flowing solutions before reaching a detector. Precision is dramatically increased when FIA is used instead of manual injections and as a result very specific FIA systems have been developed for a wide array of analytical techniques.";
    String instruments_0_instrument_external_identifier "https://vocab.nerc.ac.uk/collection/L05/current/LAB36/";
    String instruments_0_instrument_name "Flow Injection Analyzer";
    String instruments_0_instrument_nid "657";
    String instruments_0_supplied_name "Lachat QuickChem 8500";
    String instruments_1_acronym "Technicon AutoAnalyzerII";
    String instruments_1_dataset_instrument_description "Technicon AAII";
    String instruments_1_dataset_instrument_nid "743113";
    String instruments_1_description "A rapid flow analyzer that may be used to measure nutrient concentrations in seawater. It is a continuous segmented flow instrument consisting of a sampler, peristaltic pump, analytical cartridge, heating bath, and colorimeter. See more information about this instrument from the manufacturer.";
    String instruments_1_instrument_external_identifier "https://vocab.nerc.ac.uk/collection/L22/current/TOOL0291/";
    String instruments_1_instrument_name "Technicon AutoAnalyzerII";
    String instruments_1_instrument_nid "473306";
    String instruments_1_supplied_name "Technicon AAII";
    String keywords "ammonium, bco, bco-dmo, biological, btlnbr, chemical, chemistry, concentration, data, dataset, date, day, deviation, dmo, earth, Earth Science > Oceans > Ocean Chemistry > Nitrate, Earth Science > Oceans > Ocean Chemistry > Phosphate, erddap, incubation, instr, management, mass, mass_concentration_of_phosphate_in_sea_water, mole, mole_concentration_of_nitrate_in_sea_water, n02, nh4, NH4_INSTR, NH4_pcnt_RSD, NH4_STDEV, nitrate, nitrite, no2, NO2_INSTR, NO2_pcnt_RSD, NO2_STDEV, no3, NO3_NO2, NO3_NO2_INSTR, NO3_NO2_pcnt_RSD, NO3_NO2_STDEV, ocean, oceanography, oceans, office, pcnt, phosphate, po4, PO4_INSTR, PO4_pcnt_RSD, PO4_STDEV, preliminary, rsd, science, sea, seawater, SiO4, SiO4_INSTR, SiO4_pcnt_RSD, SiO4_STDEV, standard, standard deviation, stdev, time, treatment, water";
    String keywords_vocabulary "GCMD Science Keywords";
    String license "https://www.bco-dmo.org/dataset/743072/license";
    String metadata_source "https://www.bco-dmo.org/api/dataset/743072";
    String param_mapping "{'743072': {}}";
    String parameter_source "https://www.bco-dmo.org/mapserver/dataset/743072/parameters";
    String people_0_affiliation "University of South Florida";
    String people_0_affiliation_acronym "USF";
    String people_0_person_name "Kristen N. Buck";
    String people_0_person_nid "51624";
    String people_0_role "Principal Investigator";
    String people_0_role_type "originator";
    String people_1_affiliation "Old Dominion University";
    String people_1_affiliation_acronym "ODU";
    String people_1_person_name "Phoebe Dreux Chappell";
    String people_1_person_nid "636572";
    String people_1_role "Co-Principal Investigator";
    String people_1_role_type "originator";
    String people_2_affiliation "University of Rhode Island";
    String people_2_affiliation_acronym "URI";
    String people_2_person_name "Bethany D. Jenkins";
    String people_2_person_nid "558172";
    String people_2_role "Co-Principal Investigator";
    String people_2_role_type "originator";
    String people_3_affiliation "University of South Florida";
    String people_3_affiliation_acronym "USF";
    String people_3_person_name "Kristen N. Buck";
    String people_3_person_nid "51624";
    String people_3_role "Contact";
    String people_3_role_type "related";
    String people_4_affiliation "Woods Hole Oceanographic Institution";
    String people_4_affiliation_acronym "WHOI BCO-DMO";
    String people_4_person_name "Shannon Rauch";
    String people_4_person_nid "51498";
    String people_4_role "BCO-DMO Data Manager";
    String people_4_role_type "related";
    String project "Diatom_Bacteria_Ligands";
    String projects_0_acronym "Diatom_Bacteria_Ligands";
    String projects_0_description
"This project focuses on an important group of photosynthetic algae in the Southern Ocean (SO), diatoms, and the roles associated bacterial communities play in modulating their growth. Diatom growth fuels the SO food web and balances atmospheric carbon dioxide by sequestering the carbon used for growth to the deep ocean on long time scales as cells sink below the surface. The diatom growth is limited by the available iron in the seawater, most of which is not freely available to the diatoms but instead is tightly bound to other compounds. The nature of these compounds and how phytoplankton acquire iron from them is critical to understanding productivity in this region and globally. The investigators will conduct experiments to characterize the relationship between diatoms, their associated bacteria, and iron in open ocean and inshore waters. Experiments will involve supplying nutrients at varying nutrient ratios to natural phytoplankton assemblages to determine how diatoms and their associated bacteria respond to different conditions. This will provide valuable data that can be used by climate and food web modelers and it will help us better understand the relationship between iron, a key nutrient in the ocean, and the organisms at the base of the food web that use iron for photosynthetic growth and carbon uptake. The project will also further the NSF goals of training new generations of scientists and of making scientific discoveries available to the general public. The project supports early career senior investigators and the training of graduate and undergraduate students as well as outreach activities with middle school Girl Scouts in Rhode Island, inner city middle and high school age girls in Virginia, and middle school girls in Florida.
The project combines trace metal biogeochemistry, phytoplankton cultivation, and molecular biology to address questions regarding the production of iron-binding compounds and the role of diatom-bacterial interactions in this iron-limited region. Iron is an essential micronutrient for marine phytoplankton. Phytoplankton growth in the SO is limited by a lack of sufficient iron, with important consequences for carbon cycling and climate in this high latitude regime. Some of the major outstanding questions in iron biogeochemistry relate to the organic compounds that bind >99.9% of dissolved iron in surface oceans. The investigators' prior research in this region suggests that production of strong iron-binding compounds in the SO is linked to diatom blooms in waters with high nitrate to iron ratios. The sources of these compounds are unknown but the investigators hypothesize that they may be from bacteria, which are known to produce such compounds for their own use. The project will test three hypotheses concerning the production of these iron-binding compounds, limitations on the biological availability of iron even if present in high concentrations, and the roles of diatom-associated bacteria in these processes. Results from this project will provide fundamental information about the biogeochemical trigger, and biological sources and function, of natural strong iron-binding compound production in the SO, where iron plays a critical role in phytoplankton productivity, carbon cycling, and climate regulation.";
    String projects_0_end_date "2019-06";
    String projects_0_geolocation "Southern Ocean, Western Antarctic Peninsula 60-65 S, 63 W";
    String projects_0_name "Collaborative Research: Investigating Iron-binding Ligands in Southern Ocean Diatom Communities: The Role of Diatom-Bacteria Associations";
    String projects_0_project_nid "738582";
    String projects_0_start_date "2015-07";
    String publisher_name "Biological and Chemical Oceanographic Data Management Office (BCO-DMO)";
    String publisher_type "institution";
    String sourceUrl "(local files)";
    String standard_name_vocabulary "CF Standard Name Table v55";
    String subsetVariables "NH4_STDEV,NH4_pcnt_RSD";
    String summary "Dissolved macronutrient concentrations from incubation experiments performed on RVIB Nathaniel B. Palmer cruise NBP 16-08 from September to October 2016.";
    String title "Dissolved macronutrient concentrations from incubation experiments performed on RVIB Nathaniel B. Palmer cruise NBP 16-08 from September to October 2016";
    String version "1";
    String xml_source "osprey2erddap.update_xml() v1.3";
  }
}



Using tabledap to Request Data and Graphs from Tabular Datasets

tabledap lets you request a data subset, a graph, or a map from a tabular dataset (for example, buoy data), via a specially formed URL. tabledap uses the OPeNDAP (external link) Data Access Protocol (DAP) (external link) and its selection constraints (external link).

The URL specifies what you want: the dataset, a description of the graph or the subset of the data, and the file type for the response.

Tabledap request URLs must be in the form
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/datasetID.fileType{?query}
For example,
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/pmelTaoDySst.htmlTable?longitude,latitude,time,station,wmo_platform_code,T_25&time>=2015-05-23T12:00:00Z&time<=2015-05-31T12:00:00Z
Thus, the query is often a comma-separated list of desired variable names, followed by a collection of constraints (e.g., variable<value), each preceded by '&' (which is interpreted as "AND").

For details, see the tabledap Documentation.



ERDDAP, Version 2.02
Disclaimers | Privacy Policy | Contact
